Graphic designFeature

How to master colour theory

We cut through the jargon to explain the basic concepts and terminology of colour theory, in words that you can understand.

Colour is such a pervasive part of everything we visually encounter in the world, that for many designers it becomes an intuitive choice. If you think back to primary/elementary school though, you'll recall being told that there are three "primary" colours - Red, Yellow, and Blue. We were all taught that any colour can be created by mixing these three colours in varying quantities.

It turns out this isn't quite right (although it's still workable enough in practice to be taught the world over to five-year-olds).

How colour is formed

 image 1
Colour theory stretches back to at least the 15th century

Understanding how colour is formed and, more importantly, the relationships between different colours, can help you to use colour more effectively in your designs.

The Bauhaus school understood this in the 1920s and 1930s, with staff and students going on to develop colour theories for evoking particular moods and emotions through choice of palette in design and architecture.

The theory of colour is a discipline that stretches back much further than that - at least to the 15th century - and encompasses physics, chemistry and mathematics to fully define and explain the concepts. However, much of this is unnecessary to being able to use colour effectively. This quick primer will give you a handy overview of all the important aspects to help you start making informed decisions!

Colour systems

There are two primary colour systems - methods by which colour is reproduced: additive and subtractive (also known as reflective). We use both on a daily basis - the screen you're reading this article on uses additive colour to generate all the colours you see, while the book you're reading uses subtractive colour for its front cover.

In simple terms - anything that emits light (such as the sun, a screen, a projector, etc) uses additive, while everything else (which instead reflects light) uses subtractive colour.

01. Additive

 RGB
Additive colour is based on red, green, and blue - RGB for short

Additive colour works with anything that emits or radiates light. The mixture of different wavelengths of light creates different colours, and the more light you add, the brighter and lighter the colour becomes.

When using additive colour, we tend to consider the building block (primary) colours to be Red, Green, and Blue (RGB), and this is the basis for all colour you use on screen. In additive colour, white is the combination of colour, while black is the absence of colour.

02. Subtractive

 CMYK
Subtractive colour is based on cyan, magenta, and yellow

Subtractive colour works on the basis of reflected light. Rather than pushing more light out, the way a particular pigment reflects different wavelengths of light determines its apparent colour to the human eye.

Subtractive colour, like additive, has three primary colours - Cyan, Magenta, and Yellow (CMY). In subtractive colour white is the absence of colour, while black is the combination of colour, but it’s an imperfect system.

The pigments we have available to use don't fully absorb light (preventing reflected colour wavelengths), so we have to add a fourth compensating pigment to account for this limitation.

We call this "Key", hence CMYK, but essentially it's black. Without this additional pigment, the closest to black we'd be able to render in print would be a muddy brown.

The colour wheel

 Colour wheel
The modern colour wheel has been in use since the 18th century

In order to make it easier to see the relationship between different colours, the concept of the modern colour wheel was developed around the 18th century. These early wheels plotted the different primary colours around a circle, mixing different primary colours together in strict ratios to achieve secondary and tertiary colours.

The colour wheel allows us to see at a glance which colours are complementary (opposite each other on the wheel), analogous (adjacent to each other on the wheel), triadic (three colours positioned at 120 degrees on the wheel from each other) and so on.

Each of these relationships can produce pleasing colour combinations. There are many more pleasing relationships between colours based on their position on the wheel. Software such as Adobe Kuler use to help you generate effective colour themes. Read our article on choosing an effective colour scheme to learn more.

The three components of a colour

 Hue saturation
The three component parts that help us define a colour are hue, saturation and brightness

Yellow is yellow is yellow, right? Well, actually, no; there are many different colours we could refer to as yellow. Different shades or tints, saturations and hues are all possible while still being within the yellow part of the colour wheel. As a result, there are three primary component parts that help us define a colour:

01. Hue

This is the position on the colour wheel, and represents the base colour itself. This is typically referred to in degrees (around the colour wheel), so a yellow colour will appear between 50 and 60 degrees, with the perfect yellow appearing at 56 degrees. Green, meanwhile, appears at 120 degrees on the wheel at so on.

02. Saturation

This is a representation of how saturated (or rich) a colour is. Low saturation results in less overall colour, eventually becoming a shade of grey when fully desaturated. Saturation is normally referred to as a percentage between 0 and 100%.

03. Brightness

This is how bright a colour is, typically expressed as a percentage between 0 and 100%. A yellow at 0% brightness will be black, while the same yellow hue and saturation at 100% brightness will be the full yellow colour.

Colour gamut

 gamut
Colour gamut describes the range of potential colours a system can reproduce

Colour gamut is a way of describing the full range of potential colours a system can reproduce. It may surprise you to learn that the range of colours achievable in CMYK is different to that you can achieve with RGB.

This is partially because of the nature of the two different systems, but also (in the real world at least) as a consequence of limitations in our technology - screens aren’t always capable of producing the same range of colours as each other, and pigments reflect light at a non-uniform rate as you reduce their saturation.

Colour perception

Finally, it’s worth looking at how different colours can affect the way we perceive other colours. A typical illustration of this features a mid-grey tone placed over a light grey background, and the same mid-grey tone shown over a dark grey background.

The apparent brightness of the mid-grey is altered according to the context in which you see it - a trick of the eye, working to make sense of its surroundings. Hues works in the same way as tones when placed adjacent to other colours, allowing you to create different effects using the same palette of colours.

Further reading

 image 2
Click the links below to learn more about the use of colour in design

01. Digital colour mixing explained

Mixing colours digitally is not the same as mixing them physically - we explain what the difference between the two is and how to go about it in practice.

02. How to choose a colour theme

Choosing a colour theme effectively is key to the success of a design. So how do you go about choosing the best combination of colours for your project? Sam Hampton-Smith reveals all...

03. How to colour-match your print projects

Getting your colours in print to match what appears on screen, or something you’ve previously printed, isn’t always straightforward. We explain how to achieve consistency.

04. Colour management terms designers need to know

Getting your colours right means getting your head around some tricky terms. Our jargon-busting guide covers all you need to know.

05. Top colour resources

Take a look at these top online resources where you'll find tons of advice and inspiration on the subject of colour.

06. The best tools for choosing a colour scheme

Creating a colour scheme is essential to good design. We’ve gathered together some fantastic tools to help you perfect your colour choices.

07. 10 amazing uses of colour in branding

Successfully 'owning' a colour is a big deal. Here's how a succession of top brands have staked their claim...

Words: Sam Hampton-Smith
